I have been reading about Flocker for quite a while and it’s been something I have been meaning to look at since the introduction of plugins back in the Docker 1.7 release . But I have been busy looking at other parts of Docker.

Since I had a few hours this weekend I thought it was about time and had a play. ClusterHQ describes Flocker as;

Flocker is an open-source container data volume manager for your Dockerized application. It gives ops teams the tools they need to run containerized stateful services like databases in production.

Which basically means decent persistent storage, which is one thing I think Docker has been lacking when it comes to running services such as MySQL, Postgres, central logging etc.

For this test we are going to be launching three instances;

  • control.mydomain.com — Controller — This will be our cluster controller
  • flocker01.mydomain.com — Storage — Does what it says on the tin
  • flocker02.mydomain.com — Storage — Does what it says on the tin

and share keys between the root user on all three machines allowing me password-less SSH access within the cluster.

Install the command-line tools

I am going to assume you will be installing the Flocker command-line tools on a Mac. Luckily ClusterHQ have made this straight forward by provide their own Brew packages. To install the tools simply run the following commands;

Flocker on CentOS 7 1/41
brew doctor
brew tap ClusterHQ/tap
brew update
brew install flocker-1.8.0
brew test flocker-1.8.0
flocker-deploy — version

With the last two commands you should see something like the following output;

Flocker on CentOS 7 2/41
⚡ brew test flocker-1.8.0
Testing clusterhq/tap/flocker-1.8.0
==> Using the sandbox
==> /usr/local/Cellar/flocker-1.8.0/1.8.0/bin/flocker-deploy — version
russ in ~
⚡ flocker-deploy — version
1.8.0

Finally, lets create a working directory;

Flocker on CentOS 7 3/41
mkdir ~/Documents/Projects/Flocker

So thats the command line tools installed and tested, now its time to up the cluster nodes.

If you are running Linux there are instructions for installing the command line tools various distributions in the official documentation

Node Preparation

Please note — You should also transfer SSH keys between all of the nodes as mentioned at the top of this post.

The following commands need to the run on all three cluster nodes;

  • control.mydomain.com
  • flocker01.mydomain.com
  • flocker02.mydomain.com

We will be launching three CentOS 7 instances in Digital Ocean , first of all on each of the nodes run the Digital Ocean bootstrap script to get the defaults in place, and also run the Docker install script to get the latest version Docker installed and configured.

Flocker on CentOS 7 4/41
curl -fsS https://raw.githubusercontent.com/russmckendrick/DOBootstrap/master/do-bootstrap.sh | bash
curl -fsS https://raw.githubusercontent.com/russmckendrick/docker-install/master/install-offical | bash

Now add the ClusterHQ yum repo and install the packages needed to run Flocker;

Flocker on CentOS 7 5/41
yum install -y https://clusterhq-archive.s3.amazonaws.com/centos/clusterhq-release$(rpm -E %dist).noarch.rpm
yum install -y clusterhq-flocker-node clusterhq-flocker-docker-plugin

Next up create the directory where the cluster configuration will be stored and set the permissions

Flocker on CentOS 7 6/41
mkdir /etc/flocker && chmod 0700 /etc/flocker

Finally, it is important you ensure that the hostname of the machine doesn’t resolve to 127.0.0.1. Open the /etc/hosts file on each machine and remove any references as needed (for both IPv4 and IPv6);

Flocker on CentOS 7 7/41
vim /etc/hosts

Repeat this process for each of the nodes within your cluster.

Install & Configure ZFS

The following commands need to the run on the storage nodes;

  • flocker01.mydomain.com
  • flocker02.mydomain.com

We are going to be using a ZFS peer-to-peer backend, this uses the local storage on the storage nodes, at the moment it is experimental so please do not try and use it in production.

As we ran the Digital Ocean bootstrap script and changed the Kernel configuration we just need to install the kernel-devel package, this should match the running kernel. To check this run

Flocker on CentOS 7 8/41
uname -a

and check the that the version numbers match the kernel-devel package installed by the following command;

Flocker on CentOS 7 9/41
yum install -y kernel-devel epel-release

If the kernel-devel package matches the installed kernel then continue, if not please ensure that the correct kernel is selected in your Digital Ocean control panel and then try again;

The installation will take several minutes, this is normal and there is nothing to worry about if the process appears to hang during install.

Flocker on CentOS 7 10/41
sync
yum install -y https://s3.amazonaws.com/archive.zfsonlinux.org/epel/zfs-release.el7.noarch.rpm
yum install -y zfs

Once installed, load the newly compiled kernel module by running;

Flocker on CentOS 7 11/41
modprobe zfs

Now on each of the storage nodes its time to create the ZFS pool, we will be calling the pool flocker;

Flocker on CentOS 7 12/41
mkdir -p /var/opt/flocker
truncate  size 10G /var/opt/flocker/pool-vdev
ZFS_MODULE_LOADING=yes zpool create flocker /var/opt/flocker/pool-vdev

Finally, ZFS will need a key to be able access the other storage nodes, as we have already shared keys between the all the nodes run the following commands on each of the storage nodes;

Flocker on CentOS 7 13/41
cp -pr ~/.ssh/id_rsa /etc/flocker/id_rsa_flocker

Flocker Control Service

The following commands need to the run on cluster control node;

  • control.mydomain.com

At this stage we just need to enable the flocker-control service and configure firewalld with the correct ports for the service;

Flocker on CentOS 7 14/41
systemctl enable flocker-control

and for firewalld;

Flocker on CentOS 7 15/41
systemctl enable firewalld.service
systemctl start firewalld.service
firewall-cmd  reload
firewall-cmd  permanent  add-service flocker-control-api
firewall-cmd  add-service flocker-control-api
firewall-cmd  reload
firewall-cmd  permanent  add-service flocker-control-agent
firewall-cmd  add-service flocker-control-agent

You may have noticed we only enabled the service and haven’t started it, we will be doing this later in the installation.

Flocker Agent Service

The following commands need to the run on the two storage nodes;

  • flocker01.mydomain.com
  • flocker02.mydomain.com
    Firs of all lets put the put the agent configuration in place, make sure you put the hostname of your control node in the file and also make sure that you use the domain name and not the IP address;
Flocker on CentOS 7 16/41
cat >> /etc/flocker/agent.yml <<; FLOCKER_AGENT
“version”: 1
“control-service”:
 “hostname”: “control.mydomain.com”
 “port”: 4524
“dataset”:
 “backend”: “zfs”
 “pool”: “flocker”
FLOCKER_AGENT

and then enable the Flocker Agent Services by running the following commands;

Flocker on CentOS 7 17/41
systemctl enable flocker-dataset-agent
systemctl enable flocker-container-agent
systemctl enable flocker-docker-plugin

Like the control node we won’t be starting the services just yet, we need to put the authentication certificates in place first.

Generate the Cluster Certificates

Flocker uses SSL certificates for both the client & node authentication, there are a lot of them so please pay close attention to where each certificate and keys needs to be copied.

All of the certificates are generated on your local machine so make sure the following commands are all executed within the working directory we created when installing the commandline tools.

Flocker on CentOS 7 18/41
cd ~/Documents/Projects/Flocker

Certificate Authority

First of all we need to create the certificate authority, all of the other certificates will be signed using this one. We will be calling the cluster flocker;

Flocker on CentOS 7 19/41
flocker-ca initialize flocker

The cluster.key file should not be shared or copied anywhere else other than your local machine.

Control Certificate

The docs make the following notes;

  • You should replace <hostname> with the hostname of your control service node; this hostname should match the hostname you will give to HTTP API clients.
  • The <hostname> should be a valid DNS name that HTTPS clients can resolve, as they will use it as part of TLS validation.
  • It is not recommended as an IP address for the <hostname>, as it can break some HTTPS clients.

Our control node is called control.mydomain.com so we will need to run the following command;

Flocker on CentOS 7 20/41
flocker-ca create-control-certificate control.mydomain.com

Next up we need to copy the control certificate and key to the control node, give them the correct file name and set the correct permissions;

Flocker on CentOS 7 21/41
scp control-control.mydomain.com.crt [email protected]:/etc/flocker/control-service.crt
scp control-control.mydomain.com.key [email protected]:/etc/flocker/control-service.key
scp cluster.crt [email protected]:/etc/flocker/
ssh [email protected] “chmod 0600 /etc/flocker/control-service.key”

Node Certificates

Now we have the certificate in place for the control node we need to create the one for each of the storage nodes. To do this run the following command;

Flocker on CentOS 7 22/41
flocker-ca create-node-certificate

Each time you run the command you will be given a certificate with a unique ID (UID), the output should look something like;

Flocker on CentOS 7 23/41
russ in ~/Documents/Projects/Flocker
⚡ flocker-ca create-node-certificate
Created 0ed63f10–7065–4d37-af7c-6128cb5c072f.crt. Copy it over to /etc/flocker/node.crt on your node machine and make sure to chmod 0600 it.

The UID in this run was “0ed63f10–7065–4d37-af7c-6128cb5c072f”. Now we have the first node certificate and key we need to copy it to the first of our storage nodes along with the cluster.crt and set the right permissions on the key file;

Flocker on CentOS 7 24/41
scp 0ed63f10–7065–4d37-af7c-6128cb5c072f.crt [email protected]:/etc/flocker/node.crt
scp 0ed63f10–7065–4d37-af7c-6128cb5c072f.key [email protected]:/etc/flocker/node.key
scp cluster.crt [email protected]:/etc/flocker/
ssh [email protected] “chmod 0600 /etc/flocker/node.key”

Next up we need to generate a certificate for our next node, to do this run through the same steps as the first node;

Flocker on CentOS 7 25/41
flocker-ca create-node-certificate

As you can see from the following, this time we got a UID of “f939152e-0ec0–4d7c-ae74–37c899648dca”;

Flocker on CentOS 7 26/41
⚡ flocker-ca create-node-certificate
Created f939152e-0ec0–4d7c-ae74–37c899648dca.crt. Copy it over to /etc/flocker/node.crt on your node machine and make sure to chmod 0600 it.

and then copy the files and set the permissions;

Flocker on CentOS 7 27/41
scp f939152e-0ec0–4d7c-ae74–37c899648dca.crt [email protected]:/etc/flocker/node.crt
scp f939152e-0ec0–4d7c-ae74–37c899648dca.key [email protected]:/etc/flocker/node.key
scp cluster.crt [email protected]:/etc/flocker/
ssh [email protected] “chmod 0600 /etc/flocker/node.key”

Please note: It is important that each node has its own certificate, if you upload the same certificate to more than one node you will cause a conflict with the Flocker control service which will only register a single storage node.

Docker Plug-in Certificate

Next up its the turn of the Docker plug-in, on your local machine run the following commands to generate, copy and set permissions on each of the storage nodes;

Flocker on CentOS 7 28/41
flocker-ca create-api-certificate plugin
scp -r plugin.* [email protected]:/etc/flocker/
scp -r plugin.* [email protected]:/etc/flocker/

API User Certificate

Finally we should create an API user certificate, here will be calling the user flocker-russ

Flocker on CentOS 7 29/41
flocker-ca create-api-certificate flocker-russ

As we are using a Mac we will need to import the certificate into our keychain to be able to use curl to query the control node.

First of all, rename the certificate and key;

Flocker on CentOS 7 30/41
mv flocker-russ.crt user.crt
mv flocker-russ.key user.key

and then check the common name in the certificate;

Flocker on CentOS 7 31/41
openssl x509 -in user.crt -noout -subject

You should see something like;

Flocker on CentOS 7 32/41
russ in ~/Documents/Projects/Flocker
⚡ openssl x509 -in user.crt -noout -subject
subject= /OU=065c8945–8c46–4fb7–93a4-e07a3846aba0/CN=user-flocker-russ

Make a note of the “CN”, which in the example above is user-flocker-russ. Next up we need to create a .p12 certificate which can be understood by OSX, make sure you enter an export password when prompted;

Flocker on CentOS 7 33/41
openssl pkcs12 -export -in user.crt -inkey user.key -out user.p12

Finally its time to import the certificate into your keychain by running the following command which will pop-up a prompt asking for the export password you assigned;

Flocker on CentOS 7 34/41
security import user.p12 -k ~/Library/Keychains/login.keychain

Reboot everything

We will be rebooting the following nodes;

  • control.mydomain.com
  • flocker01.mydomain.com
  • flocker02.mydomain.com

Now the nodes are prepared, all of the authentication certificates generated and shared across the cluster it’s time to reboot the control & storage nodes. To do this run the following command on each of the servers;

Flocker on CentOS 7 35/41
reboot

Once rebooted we can start to test the cluster.

Testing the Cluster

Now everything is rebooted we should have a working Flocker cluster.

API Connection

First of all lets make a connection to the Flocker Control API and list the nodes. The following command will connect using the API certificate we imported into the Keychain, this is called by using the CN which was user-flocker-russ;

Flocker on CentOS 7 36/41
curl — cacert ~/Documents/Projects/Flocker/cluster.crt — cert “user-flocker-russ” https://control.mydomain.com:4523/v1/state/nodes

You should see something like the following output;

Flocker on CentOS 7 37/41
russ in ~/Documents/Projects/Flocker
⚡ curl — cacert ~/Documents/Projects/Flocker/cluster.crt — cert “user-flocker-russ” https://control.mydomain.com:4523/v1/state/nodes
[{“host”: “123.123.123.1”, “uuid”: “0ed63f10–7065–4d37-af7c-6128cb5c072f”}, {“host”: “123.123.123.2”, “uuid”: “f939152e-0ec0–4d7c-ae74–37c899648dca”}]

As you can see both nodes, with the UIDs of the node certificates are showing.

Docker Plugin test

Now you have the nodes talking to the control node its time to try and launch a container;

Flocker on CentOS 7 38/41
docker run -v wibble:/data — volume-driver flocker busybox sh -c “echo Hello from Flocker > /data/file.txt”

You should see something like the following output;

Flocker on CentOS 7 39/41
[root@flocker02 ~]# docker run -v wibble:/data — volume-driver flocker busybox sh -c “echo Hello from Flocker > /data/file.txt”
Unable to find image busybox:latest locally
latest: Pulling from library/busybox

c00ef186408b: Pull complete
ac6a7980c6c2: Pull complete
Digest: sha256:e4f93f6ed15a0cdd342f5aae387886fba0ab98af0a102da6276eaf24d6e6ade0
Status: Downloaded newer image for busybox:latest
[root@flocker02 ~]#

Now you have written to “wibble:/data” you can launch another cotainer which remounts “wibble:/data” and prints the content of “/data/file.txt” to the screen;

Flocker on CentOS 7 40/41
docker run -v wibble:/data — volume-driver flocker busybox sh -c “cat /data/file.txt”

You should see the following;

Flocker on CentOS 7 41/41
[root@flocker02 ~]# docker run -v wibble:/data — volume-driver flocker busybox sh -c “cat /data/file.txt”
Hello from Flocker
[root@flocker02 ~]#

Further Testing

Now you have the basics tested you should be able to start working through some of the more advanced examples from the official documentation like;
