Puppet Enterprise & AWS Security Groups
This week I had to do a few installations of Puppet Enterprise on an EC2 instance. Although this seemed like a simple enough task, I did hit upon one annoying issue.
I was doing a Monolithic installation as it was just for testing, I had done this several times on Digital Ocean and locally using a Vagrant box with no issue at all. Reading through the documenation I had to open the following
8140
- The Puppet master uses this port to accept inbound traffic/requests from Puppet agents.
- The PE console sends request to the Puppet master on this port.
- Certificate requests are passed over this port unless ca_port is set differently.
443
- This port provides host access to the PE console.
- The PE Console accepts HTTPS traffic from end-users on this port.
61613
- MCollective uses this port to accept inbound traffic/requests from Puppet agents for orchestration.
- Any host used to invoke orchestration commands must be able to reach MCollective on this port.
That seemed simple enough, however when I create a security group with those ports open to world, also as I was using the web based installer I opened port 3000 to my IP address, just in-case come script kiddie decided to do the installation for me.
Everything ran as expected until the installation got to “Waiting for Node Classifier to start” and then it hung;
PuppetDB configured.Waiting for Node Classifier to start…** HTTP_PROXY= http_proxy= HTTPS_PROXY= https_proxy= /opt/puppetlabs/puppet/bin/curl — tlsv1 -s — cacert /etc/puppetlabs/puppet/ssl/certs/ca.pem — key /opt/puppetlabs/server/data/console-services/certs/puppet.mckendrick.io.private_key.pem — cert /opt/puppetlabs/server/data/console-services/certs/puppet.mckendrick.io.cert.pem https://puppet.mckendrick.io:4433/classifier-api/v1/last-class-update | grep -q last_update.*[[:digit:]]** HTTP_PROXY= http_proxy= HTTPS_PROXY= https_proxy= /opt/puppetlabs/puppet/bin/curl — tlsv1 -s — cacert /etc/puppetlabs/puppet/ssl/certs/ca.pem — key /opt/puppetlabs/server/data/console-services/certs/puppet.mckendrick.io.private_key.pem — cert /opt/puppetlabs/server/data/console-services/certs/puppet.mckendrick.io.cert.pem https://puppet.mckendrick.io:4433/classifier-api/v1/last-class-update | grep -q last_update.*[[:digit:]]** HTTP_PROXY= http_proxy= HTTPS_PROXY= https_proxy= /opt/puppetlabs/puppet/bin/curl — tlsv1 -s — cacert /etc/puppetlabs/puppet/ssl/certs/ca.pem — key /opt/puppetlabs/server/data/console-services/certs/puppet.mckendrick.io.private_key.pem — cert /opt/puppetlabs/server/data/console-services/certs/puppet.mckendrick.io.cert.pem https://puppet.mckendrick.io:4433/classifier-api/v1/last-class-update | grep -q last_update.*[[:digit:]]** HTTP_PROXY= http_proxy= HTTPS_PROXY= https_proxy= /opt/puppetlabs/puppet/bin/curl — tlsv1 -s — cacert /etc/puppetlabs/puppet/ssl/certs/ca.pem — key /opt/puppetlabs/server/data/console-services/certs/puppet.mckendrick.io.private_key.pem — cert /opt/puppetlabs/server/data/console-services/certs/puppet.mckendrick.io.cert.pem https://puppet.mckendrick.io:4433/classifier-api/v1/last-class-update | grep -q last_update.*[[:digit:]]** HTTP_PROXY= http_proxy= HTTPS_PROXY= https_proxy= /opt/puppetlabs/puppet/bin/curl — tlsv1 -s — cacert /etc/puppetlabs/puppet/ssl/certs/ca.pem — key /opt/puppetlabs/server/data/console-services/certs/puppet.mckendrick.io.private_key.pem — cert /opt/puppetlabs/server/data/console-services/certs/puppet.mckendrick.io.cert.pem https://puppet.mckendrick.io:4433/classifier-api/v1/last-class-update | grep -q last_update.*[[:digit:]]
I tried running the curl command manually and got the same problem;
/opt/puppetlabs/puppet/bin/curl — tlsv1 -s — cacert /etc/puppetlabs/puppet/ssl/certs/ca.pem — key /opt/puppetlabs/server/data/console-services/certs/puppet.mckendrick.io.private_key.pem — cert /opt/puppetlabs/server/data/console-services/certs/puppet.mckendrick.io.cert.pem https://puppet.mckendrick.io:4433/classifier-api/v1/last-class-update
It was obviously an issue with the security group as when I added an allow all rule and re-ran the installer it worked without issue, however after the installation completed I removed the allow all rule and I could no longer login to the Puppet Enterprise Dashboard.
After repeating the installation a few times I managed to track the issue down to the way that Puppet interacts with itself. To resolve the issue I had to add an allow all for both external IP address and the internal IP address.
While this feels like a bit of a fudge it solved the issue with both the installer and the dashboard.
If anyone knows a more elegant fix for this please let me know in the comments below.
