Quick OpenStack Kilo Installation

I am going to be playing with OpenStack over the next few weeks so I decided to create a Vagrant script which would bootstrap a working OpenStack Kilo↗ installation using RedHat RDO↗.

It uses my CentOS 7 Vagrant box↗ and works with both VirtualBox and VMWare Fusion.

To get it up and running create a folder for the Vagrantfile to live;

mkdir -p ~/Machines/OpenStack/

Download a copy of the Vagrantfile;

curl -O https://gist.githubusercontent.com/russmckendrick/49700dbf18ac2d7fbbfa/raw/46c367fa9d257bab46affe15a19904c9d5171be9/Vagrantfile > ~/Machines/OpenStack/Vagrantfile

and start the machine up;

 cd ~/Machines/OpenStack/
 vagrant up # for VirtualBox
 vagrant up — provider vmware_fusion # for VMWare Fusion

It will take around 20 minutes to bootstrap the machine so make a cup of tea and watch this introduction to Kilo;

Feel free to reuse the Vagrantfile if you like;

# -*- mode: ruby -*-
# vi: set ft=ruby :
# Vagrantfile API/syntax version. Don't touch unless you know what you're doing!

VAGRANTFILE_API_VERSION = "2"
BOX_NAME = 'russmckendrick/centos7'
BOX_IP = '192.168.0.42'
HOSTNAME = 'rdo'
DOMAIN   = 'vagrant.dev'
Vagrant.require_version '>= 1.4.0'
Vagrant.configure(VAGRANTFILE_API_VERSION) do |config|

config.vm.box = BOX_NAME

config.vm.network :private_network, ip: BOX_IP

config.vm.host_name = HOSTNAME + '.' + DOMAIN

config.vm.synced_folder "./", "/vagrant", id: "vagrant-root",
    owner: "vagrant",
    group: "nobody",
    mount_options: ["dmode=777,fmode=755"]

config.vm.provider "virtualbox" do |v|
  v.memory = 4048
  v.cpus = 4
end

config.vm.provider "vmware_fusion" do |v|
  v.vmx["memsize"] = "4048"
  v.vmx["numvcpus"] = "4"
end

$script = <<SCRIPT
set -e
set -x
sudo systemctl stop NetworkManager
sudo systemctl disable NetworkManager
sudo systemctl enable network
sudo yum install -y https://rdoproject.org/repos/rdo-release.rpm
sudo yum install -y openstack-packstack
INTERNALIP=$(ifconfig | grep "inet" | grep "10.0.2" | awk '{ print $2 }')
EXTERNALIP=$(ifconfig | grep "inet" | grep "192.168" | awk '{ print $2 }')
sudo /usr/bin/packstack --gen-answer-file=/tmp/answers
sudo sed "s/$INTERNALIP/$EXTERNALIP/g" /tmp/answers > /tmp/answers-external
sudo /usr/bin/packstack --answer-file=/tmp/answers-external
echo ""
echo "**** Logins ******"
echo ""
sudo cat /root/keystonerc_admin
echo ""
SCRIPT

config.vm.provision "shell",
    inline: $script

end
